Overview

This document describes the contents, installation, and use of the Label Taken Sensor option for the MP

Compact printers. After verifying the contents of the kit and the tools needed, follow the steps below to

install and begin using the option.


CAUTION

For your safety and to avoid equipment damage, always turn ‘Off’ power and unplug the

printer’s power cord before beginning this installation and when performing service.


Contents of the Label Taken Sensor Kit


This kit contains the following item:

1 x LTS Compact
1 x Cover LTS
1 x Screw (MRX 3x8)
1 x Washer (BRB 3.2)
1 x Screw (RXS Z)
1 x Cable Clamp

Tools Required


To install this option, you will need

Drillbit, 2.5 mm
Phillips

Screwdriver
