Datamax-O'Neil microFlash 2te IP54 Cases - Manual

Congratulations! You’ve just purchased an accessory
that will allow your rugged Datamax-O’Neil printer to
go the extra mile. Proper use of this case will allow our
MF2te Series printer to be used in harsh, dusty, or
rainy environments.
This case is certified to be an IP54 rating, so when
properly used, it will protect your product against
particles as small as dust, and water from any
direction.
Installation Instructions
1. Remove the case from any protective wrapping and
packaging.
2. Unzip the case to install the printer.
3. Install the printer (Figure 1). Be sure that the
printer’s edges will be encased by the printer case.
Figure 1
4. Zip the printer flap to secure the printer in place
(Figure 2).
Figure 2
5. Close the top cover, then secure all covers with the
hook and loop fasteners provided.
6. Access the power jack by partially unzipping case
and insert plug into printer (Figure 3).
Figure 3
Options
• The printer can be worn in the IP54 case with a
swivel belt clip or swivel belt loop (Figure 4).
Figure 4
• The printer can be worn with a shoulder strap
(included) (Figure 5).
Figure 5
• The top cover flap can also be velcroed to the top
of the case to allow easier removal of media while
maintaining additional protection to the printer
(Figure 6 and 7). (NOTE: This configuration does
not offer full IP54 protection.)
Figure 6
Figure 7
NOTE: These cases are not compatible with MF2te
printers that include the optional magnetic stripe card
reader.
NOTE: When the printer is in transport or not in use, it
is necessary to fully secure the paper flaps to allow
maximum protection of the printer.
