N e t w o r k S e t u p 6
Network Card Setup - Wireless (Infrastructure Mode)
After a successful setup is made via a wired connection, the
Wireless connection (if equipped) can now be configured in
infrastructure mode using an static or DHCP issued IP address.
1. Open your web browser. Type in the IP Address of the printer. The
Default IP is: 192.168.10.26.
 Note: If you have assigned different IP Address to the printer,
make sure to enter the correct IP Address.
2. The page to the right will appear:
3. Click on the TCPIP Configuration menu item. Locate and set the following items:
> Activate the “Enable Wireless” setting by clicking on the check box.
For static IP setup:
> Enter valid static IP addresses for “IP Address”, “Subnet Mask”, and “Default Gateway”
> Un-check the “Enable IP Discovery” check box.
Scroll down to the bottom of the page, enter the password (default is “sysadm”) and click apply.
4. Click on the WiFi Configuration menu item. Locate and set the following items:
> Set the SSID field to match the SSID of your access point.
> Set WLAN Network Type drop down box to “Infrastructure”.
> Set any WLAN Security Settings if necessary.
For static IP setup:
> Set the “Static BSS Address”. This is the address assigned to the radio portion of the network card, it
must be an unique address.
Scroll down to the bottom of the page, enter the password (default is “sysadm”) and click apply.
5. Click on the Reset Network Parameters menu item, enter the password and click Reset.
Once the previous steps have been successfully completed you may now use the IP Address to:
> Install a printer driver, and start printing from your Windows applications. See section, Installing the Printer Driver.
-or-
> Browse to the printer’s internal web pages for advanced configuration. See section, Printer’s Internal Web Pages.
