Datamax-O'Neil I-Class Mark II Wired_Wireless LAN Option User Manual
Page 8
8
D) Insert the Antenna Connector through the hole in the printer’s Back Panel.
E) Re-install the Nut and Washer onto the Antenna Connector and tighten using a 5/16”
or 8mm Wrench.
F) Connect the Antenna Connector Wire to the connector on the Wireless Module.
Antenna
Connector
Back
Panel
Nut
Washer
Antenna
Connector
Wire
Wireless
Module
