Page 3 DeviceNet Heavy Duty Datasheet Version: 20130507
HEA VY DUT Y INCLI NO ME T E R
DEVI CE NET INT ERF ACE
MTBF Data
Failure Rate [FIT] 759
MTBF [Hours] 1,317,822
MTBF [Years] 150
The above mentioned data were calculated for electronics under the following conditions:
SNA: Non-mobile operation
Tu: 40°C - Mean component of ambient temperature
Zf: Continuous operation for 8760 h per year
Programmable Parameters
Resolution per 1° The resolution parameter per 1° is used to program the desired
number of steps per 1°. The values 1, 10 and 100 can be
programmed. Default setting: 100.
Preset Value The Preset value is the desired position value, which should be
reached at a certain physical position of the axis. The position value
is set to the desired process value by the preset parameter.
Digital recursive filter This filter can be used to adjust the bandwidth of measuring values
to minimize the influence of vibration.
Factory Setting: Moving average filter activated for 20 subsequent
readouts.
Transmission rate Adjustable; 125 kBaud, 250 kBaud, or 500 kBaud
Factory Setting: 125 KBaud
Address (MAC-ID) Factory setting: Node ID = 63, Adjustable from 0 to 63
Programmable DeviceNet Transmission Modes
Polled Mode Through an I/O-request telegram the connected host calls for the
current process value. The inclinometer reads the current inclination
value, calculates the eventually set-parameters and sends back the
obtained process value.
Cyclic Mode The inclinometer transmits cyclically - without being called by the
host - the current process value. The cycle time can be programmed
in milliseconds for values between 1 ms and 65536 ms.
Change-of-State Mode The inclinometer answers with current process value in case a
change of inclination is detected.
