Page 2 DeviceNet Heavy Duty Datasheet Version: 2012-02-29
HEA VY DUT Y INCLI NO ME T E R
DEVI CE NET INT ERF ACE
Technical Data
Electrical Data
Model INC -080 INC -360
Measuring Range ± 80° 360°
Number of Axes 2 1
Resolution 0.01°
Accuracy (T =

10 °C to +40 °C)* 0.1°
Sensor Response Time 10 ms (without filter)
Recommended Measurement
Rate
Up to 10 Hz
Interface DeviceNet
Transceiver according to ISO 11898,
Galvanically isolated by Opto-couplers
Transmission Rate Adjustable:125 KBaud, 250 KBaud, 500 KBaud
Factory Setting : 125 kBaud
Addressing Programmable
Supply Voltage 10 to 30 V DC (Absolute Maximum Ratings)
Current Consumption Max. 57 mA at 10 V DC, Max. 53 mA at 24 V DC
EMC Emitted interference: EN 61000-6-4*
Noise immunity: EN 61000-6-2*
Connection Connector
INC- …. - PM
8 Pin M12 male (A-coded)
Connection Cable
INC- …. – DW-…
Ø 7.1 mm [0.28 in] Polyurethane: 4 x 2 x 0.34 mm
2
[AWG 22]
Mechanical Data
Housing Material Aluminium Alloy
Potting Material Polyurethane
Shock (EN 60068-2-27)*

100 g (half sine, 6 ms)
Vibration (EN 60068-2-6)* 1.5 mm (10 Hz to 58Hz) &

20 g (58 Hz to 2000 Hz)
Weight 170 gm / 6 oz
Environmental Conditions
Operating Temperature -40 °C to +85 °C / -40 °F to 185 °F
Humidity 98 % Relative Humidity
Protection Class (EN 60529) IP 69K (With Appropriate Mating Connector) , IP68, IP67
*further data available on request
