Page 2 SSI Industrial Datasheet Version 20130723
INDUST RIAL I NCLI NOMET ER 3 60°
SYNCHRONOUS S E RIAL INT E RFA CE ( S S I)
Technical Data
Electrical Data
Model INC 360
Measuring Range 360°
Number of Axes 1
Resolution 13 Bit (0.04°)
1
Accuracy 0.14°
Sensor Response Time 100ms ± 10%
1
Interface Synchronous Serial Interface (SSI)
Current Consumption <250mA at 5V DC, <100 mA at 10 V DC, <80 mA at 24 V DC
Power consumption below 1.5 W
Clock Input Via opto-coupler
Data Output Line-driver according to RS 422
Clock Frequency 100 kHz – 2 MHz
Supply Voltage 4.5 – 30 V DC (absolute maximum ratings) 2
Turn on time < 1 s
EMC Emitted interference: EN 61000-6-4
Noise immunity: EN 61000-6-2
1) Changes in response time and Resolution on request
2) According EN 50178 (SELF)
Mechanical Data
Housing Material Glass Fiber Reinforced PBT (Polybutylene Terephthalate)
(UV-Stabilized, UL 94-V0 Standard)
Potting Material PUR (Polyurethane)
Weight 75 g [3 oz]
Environmental Conditions
Operating Temperature -40 °C to +85 °C [-40 °F to 185 °F]
Protection class (EN 60529) IP 69K & IP68 (With Appropriate Mating Connector)
Shock (EN 60068-2-27) 
100 g (half sine, 6 ms)
Vibration (EN 60068-2-6) 1.5mm (10 to 58 Hz)

20 g (58 to 2000 Hz)
