GOLD PLUS 6V/12V Intelligent Battery Tester
STEP 2 Make the Correct Connection
Observing polarity, connect the test lead clips exactly as described
for the types of battery terminals shown below, RED+ and BLACK-
WARNING: Maximum input voltage 15VDC
Grip clips tightly around tab
terminals
CORRECT
Insert clips fully inside
battery terminals
CORRECT
Grip tightly around posts
using spikes
CORRECT
DO NOT connect to high
resistance bolts
INCORRECT
