If the alarm system is triggered while armed, the system will retain in memory the cause of the
trigger. The diagnostics can then be used to determine what the cause of the trigger was. When
disarming the alarm, the siren/horn will chirp 3 times instead of the usual 2 times to indicate the
alarm had been triggered.
The system’s LED will also flash in pulses to indicate which input triggered the alarm.
NOTE: LED status will be cleared when ignition is turned ON. For proper memory clearing, insure
to connect the ignition input to the ignition on the vehicle.
Alarm Diagnostics
Diagnostics Chart
Diagnostics
Additional LED Flashes
Park Light Flashes LED Flashes Diagnostic
Two Flashes Two Flashes Shock Sensor Triggered
Three Flashes Three Flashes Door Input Triggered
Four Flashes Four Flashes Ignition Input Triggered
Five Flashes Five Flashes Hood Input Triggered
None Off System Disarmed
None On Solid Valet/Service Mode
None Single Flashes System Armed
None Rapid Flashes Passive Arming
On/Off Rapid Flashes Car Jack Mode
