CHIEF NS1D12-20-28-36-41 User Manual
Page 6
NS1D12-20-28-36-41
Installation Instructions
6
Figure 9
DANGER:
IMPROPER WIRING CAN LEAD TO DEATH
OR SEVERE PERSONAL INJURY! Grounding must be
installed by qualified personnel using a UL Recognized No.
12AWG Green and Yellow grounding wire connected to
grounding lug on rack.
(inside view of door)
Grounding screw and nut
installed at factory
affixed adjacent to grounding terminal.
Earthing symbol IEC 60417 No. 5019
Location of
grounding
lugs
