PACCC2

Installation Instructions

2

DISCLAIMER

Milestone AV Technologies and its affiliated corporations and
subsidiaries (collectively "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.

Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.

IMPORTANT SAFETY INSTRUCTIONS

WARNING:

A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION:

A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the
corresponding instructions.

WARNING:

Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are

properly assembled and installed using the instructions
provided.

WARNING:

Failure to provide adequate structural strength

for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.

WARNING:

Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached to the PACCC2 does not exceed 35
lbs (16 kg).

WARNING:

Use this mounting system only for its intended

use as described in these instructions. Do not use
attachments not recommended by the manufacturer.

WARNING:

Never operate this mounting system if it is

damaged. Return the mounting system to a service center for
examination and repair.

WARNING:

Do not use this product outdoors.

--SAVE THESE INSTRUCTIONS--

DIMENSIONS

7.9

200

14.00

356

14.00

356

4X .28

2.13

7.38

10.00

2X 1.50

2X 2.00

1.75

17.09 [434] MIN

23.83 [605] MAX

HALF THE HEIGHT OF THE SCREEN PLUS

HALF THE HEIGHT OF THE SPEAKER

APPROX CENTER

OF SCREEN

APPROX CENTER

OF SPEAKER

33.58 [853] MAX

26.84 [682] MIN

PRELOAD

FOR SPEAKER

2.91

73.9

OPENINGS IN ASSEMBLY FOR PACLR2

LEFT AND RIGHT SPEAKER RAILS

17.22

437.4

.62

SPEAKER DEPTH ADJ.

16

10°

ANGULAR

SPEAKER ADJ.

10°

ANGULAR

SPEAKER ADJ.

DIMENSIONS: [MILLIMETERS]
INCHES
