CHIEF MAC251 User Manual
Page 6
MAC-251
Installation Instructions
6
CAUTION:
Latching flag must fully engage mounting
button.
4.
Secure display by rotating latching flag to the LATCHED
position. If latching flag does not fully engage, ensure
mounting buttons are fully seated in teardrop slots. (See
Figure 7)
NOTE:
A hole is provided in the latching flag and CPU holder
to accommodate insertion of a padlock or similar
locking device.
Figure 7
5.
Connect cables to display.
Latching
4
LATCHED
(A)
Mounting Button
(On interface bracket
or display)
flag
CPU
Hole for padlock
or other locking
device
