CHIEF CMS Series Columns - Manual (Page 4)

CMS Series Columns Installation Instructions
4
TOOLS REQUIRED FOR INSTALLATION
PARTS
7/32" (5.5mm) #2
1/2" (12.7mm)
C (1) D (1) E (1) F (2) H (2) J (1)
5/16" x 5/8" 5/16" 5/16" 5/16" x 1/4" 5/16" x 1/4" 3/16"
(7.9mm x 15mm) (7.9mm) (7.9mm) (7.9mm x 6.4mm) (7.9mm x 6.4mm) (4.8mm)
G (1)
5/32"
(4.0mm)
[CMS adjustable length]
or
A (1)
[CMS fixed length]
A (1)
*Parts B-J only included with adjustable length columns
B (1)
