CHIEF CMS Series Columns - Manual (Page 3)

Installation Instructions CMS Series Columns
3
DIMENSIONS
LEGEND
Fixed Length Column Adjustable Length Column
2.0
1.90 OD
2.31 OD
1.19
FULLY EXTENDED
ALL THREADS
1-1/2" NPT
MIN LENGTH
OUTER TUBE
LENGTH
1.00
1.00
FULLY RETRACTED
1.50 ID
LENGTH
1.125
DIMENSIONS: INCHES
[MILLIMETERS]
Security Wrench
Llave de seguridad
Sicherheitsschlüssel
Chave de segurança
Chiave di sicurezza
Veiligheidssleutel
Clé de sécurité
Hex-Head Wrench
Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleutel
Clй а tête hexagonale
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
By Hand
A mano
Von Hand
Com a mão
A mano
Met de hand
À la main
Optional
Opcional
Optional
Opcional
Opzionale
Optie
En option
