Installation Instructions PCS Series
3
DIMENSIONS
LEGEND
7.25
TOP MOUNTING BUTTON
ON PSBU GOES HERE
APPROXIMATE CENTER
OF DISPLAY
3.64
7.68
FACE TILTS
5 UP
20 DOWN
1.25
4.19
1-1/2" NPSM NOTE: PSBU INTERFACE BRACKETS
NOT SHOWN. THE PSBU INTERFACE
BRACKET WILL ADD 1” IN DEPTH
AND MAY AFFECT THE LOCATION
OF THE DISPLAY ON THE MOUNT.
DIMENSIONS: INCHES
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Open-Ended Wrench
Llave de boca
Gabelschlüssel
Chave de bocas
Chiave a punte aperte
Steeksleutel
Clй а fourche
Hex-Head Wrench
Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleutel
Clй а tête hexagonale
