CHIEF PDC Series - Manual (Page 3)

Installation Instructions PDC Series
3
DIMENSIONS
LEGEND
APPROXIMATE CENTER OF DISPLAY
ON PSBU GOES HERE
1-1/2" NPSM
FACE TILTS UP 5
DOWN 25
[BOTH SIDES]
NOTE: PSBU INTERFACE BRACKETS
NOT SHOWN. THE PSBU INTERFACE
BRACKET WILL ADD 1” IN DEPTH AND
MAY AFFECT THE LOCATION OF THE
DISPLAY ON THE MOUNT.
DIMENSIONS: INCHES
[MILLIMETERS]
