TAILWHEEL HUB ASSEMBLY
ITEM
PART NO. QTY.
DESCRIPTION
00780238
1
ASSY, TAILWHEEL HUB
1
00776214
1
HUB 4 BOLT
2
00776213
2
BEARING
3
00759635
4
FLATWASHER 1/2 HARDND NONPLATD
4
00762462
4
HEXB METRIC 12-P1.75- 25MM PL5
5
00772017
2
BUSHING SPINDLE STEP
6
00772018
2
DUST CAP
7
00776219
2
SEAL OIL 40 X 62 X 8
8
00776211
1
BOLT SPINDLE M24 X 2 X 186
9
00776217
2
WASHER FLAT 026 X 044 X 4 FLAT
10
00776212
1
NUT SPINDLE M24 X 2
11
00772082
1
NIPPLE, GREASE M8X1
12
00771620
1
PIN,COTTER 5/32X2-1/2 PL
©2010 Alamo Group Inc.
Parts Section -41
RX60 - RX72 - RX84 (01-10) Rev 05-11
