Page 41
SLIP CLUTCH ASSEMBLY CAT-5 - RX84
ITEM
PART NO. QTY.
DESCRIPTION
1
00775383
1
YOKE FLANGE
2
0921000462
4
DISK, CLUTCH 5-15/16X3-19/32X
3
00779366
1
HUB 1-3/4-20
4
00775335
1
DRIVE PLATE
5
00779365
1
DRIVE PLATE
6
00775337
1
THRUST PLATE
7
00775338
6
BOLT HEX M12 X P1.25 X 115M
8
00775339
6
COMPRESSION SPRING
9
00754566
6
LOCKWASHER, 12MM
10
00756164
6
NUT METRIC 12MM-P1.75 GR.8.8
11
00774208
1
LOCK ASY CC YOKE
©2010 Alamo Group Inc.
Parts Section -37
RX60 - RX72 - RX84 (01-10) Rev 05-11
