American Standard Colony 5-1/2' x 32

H76
© 2008 AS America Inc.
COLONY™ 5-1/2' x 32" w/INTEGRAL APRON
WHIRLPOOL AND BATHING POOL
HIGH GLOSS
Revised 2/08
66” (1676mm)
WATER RETENTION
FLANGE (3 SIDES) FINISHED
WALL
7-1/4” (184mm)
C/L OF DRAIN
3/4” (19mm)
15-1/2"
(394mm)
32”
(813mm)
1-1/2”
(38mm)
C/L OF
SUPPLIES
2-3/8 ± 1/2
(60 mm ± 13 mm)
C/L OF DRAIN
OUTLET
19-1/4
(489mm)
REF.
DIM
1" WATER
RETENTION
FLANGE
(3 SIDES)
19-1/2
(459mm)
1-1/2 O.D.TAILPIECE
BATH
SUPPORT
MATERIAL
ROUGH
FLOOR
FINISHED
WALL
TOP OF
DECK
3-1/4
(83mm)
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
65 & 78
(1651 & 1981mm)
C/L OF
OVERFLOW
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
2-3/4
(70mm)
4-5/8
(117mm)
1-1/2 N.P.T.M.
THREADS
UNDERSIDE
OF DECK
ON/OFF SWITCH
PUMP
12
(305mm)
OPT. 4
(102mm)
LEVELING
STRINGER
NOT FOR
SUPPORT
TILING
FLANGE
66” (1676mm)
WATER RETENTION
FLANGE (3 SIDES) FINISHED
WALL
7-1/4” (184mm)
C/L OF DRAIN
3/4” (19mm)
15-1/2"
(394mm)
32”
(813mm)
1-1/2”
(38mm)
C/L OF
SUPPLIES
2-3/8 ± 1/2
(60 mm ± 13 mm)
C/L OF DRAIN
OUTLET
19-1/4
(489mm)
REF.
DIM
1" WATER
RETENTION
FLANGE
(3 SIDES)
19-1/2
(459mm)
1-1/2 O.D.TAILPIECE
BATH
SUPPORT
MATERIAL
LEVELING
STRINGER
NOT FOR
SUPPORT
ROUGH
FLOOR
FINISHED
WALL
TOP OF
DECK
3-1/4
(83mm)
12
(305mm)
OPT.
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
65 & 78
(1651 & 1981mm)
C/L OF
OVERFLOW
4
(102 mm)
C/L OF
SPOUT
TILING
FLANGE
C/L OF
VALVES
C/L OF
SHOWER ARM
2-3/4
(70mm)
4-5/8
(117mm)
1-1/2 N.P.T.M.
THREADS
UNDERSIDE
OF DECK
66 x 32 x 19-1/2 In.(1676 x 813 x 495mm)
120 Lbs. (54 Kg.)
537 Lbs. (244 Kg.)
50 Gal. (189 L.)
46 Gal. (174 L.)
18 x 48 In. (457 x 1219mm)
26 x 59 In.(660 x 1499mm)
12-1/2 In. (318 mm)
37 Lbs./Sq. Ft. (179 Kgs/Sq. m.)
20.8
35.3
GENERAL SPECIFICATIONS FOR 1748 WHIRLPOOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
WHIRLPOOL MIN. OPERATING VOL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT
3 )
WHIRLPOOL ELECTRICAL SPECIFICATIONS
1.25 HP, 9.9 AMPS, 120V. SYSTEM I PUMP
66 x 32 x 19-1/2 In.
(1676 x 813 x 495mm)
100 Lbs. (45 Kg.)
517 Lbs. (235 Kg.)
50 Gal. (189 L)
18 x 48 In. (457 x 1219mm)
26 X 59 In. (660 x 1499mm)
12-1/2 In. (318mm)
35 Lbs./Sq.Ft. (173 Kgs./Sq.m)
25.6
29.7
GENERAL SPECIFICATIONS FOR 1748 BATHING POOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
NOTES:
BATH TO BE INSTALLED ABOVE FLOOR LINE AS A RECESS INSTALLATION. SUPPORT OF BATH BY SUMP BEDDING. SUPPORT AND
ENCLOSING MATERIAL BY OTHERS.
■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
LEFT HAND OUTLET SHOWN, RIGHT HAND REVERSE DIMENSIONS.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT: Dimensions of fixtures are nominal and may vary within the range of tolerances established by ANSI Standards Z124.1 and
A112.19.7. These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided pages.
