Table of Contents
Safety Notification_______________ Page 1
Machine Inventory_______________ Page 2
Machine Requirements____________ Page 2
Setting Up______________________ Page 3
Operating Instruction_____________ Page 5
Machine Adjustments
Router Feed Rate Adjustment____________ ___ 6
Drill Feed Rate Adjustment_________________ 7
Pilot Drill Depth Adjustment________________ 7-8
Pilot Hole Height Adjustment_______________ 8
Pocket Depth Position__________________ ___ 9
Pocket Distance Adjustment_____________ ___ 9
Changing the Bits on your Machine __________ 10
Definition and Description of Parts__ Page 12-13
Maintenance
Machine________________________________ 14
Motors and Bits_______________________ ___ 15
Troubleshooting
Machine Will Not Start The Cycle___________ 16-17
Clamp Is Releasing Slowly_________________ 18-20
The Router Cuts The Pocket But The
Clamp Doesn’t Release____________________
20
The Pocket Is Being Cut And The Drill
Comes Up But Doesn’t Finish The Pilot Hole___
21-24
Warranty Information_____________ Page 25
