Chapter 5: Maintaining Your Washer
Product Service 1-800-522-7658 34
5. Remove the four screws from the valve plate and separate the valve from the
inlet connection.
6. Remove the valve filter screen and clean it under running water.
7. Replace the screen and reassemble the valve connection. Be certain the O-ring
gasket is positioned in the groove in the fill valve body.
Replacing the Washer Light Bulb
If your Glassware Washer is equipped with a window, you will need to
periodically replace the light bulb. Refer to the figure below and follow the
instructions below to replace the washer light bulb.
To replace the washer light bulb:
1. Turn off electrical power to the Glassware Washer.
2. Remove the lower and middle panels as described in Chapter 3: Getting
Started, Connecting the Power Supply.
3. Disconnect the springs on each side that connect the pivot brackets to the
washer base. Disconnect the hook on the washer base side.
4. Remove the two screws on each side of the outer door panel. Lower the panel
and remove it.
5. Remove the bulb by pressing in on the bulb and rotating the bulb
counterclockwise.
6. Insert the new bulb and rotate clockwise into place.
7. Replace the outer door panel.
