NEULOG PHOTO GATE SENSOR GUIDE
Operation with NeuLog viewer
Materials needed:
Procedure:
1. Connect the photo gate sensor to the left side of the viewer.
2. Connect the BAT-200 module to the right side of the viewer.
3. The VIEW-101 will auto detect the sensor and you will see it
appear on the left side of the screen.
4. Once the sensor appears it will be monitoring data in real time.
5. To run an experiment and collect data click the run button (little
green person).
Off-line experiments
(Off-line experiments are for when you do not have a sensor connected
directly to a computer, tablet, smartphone, or NeuLog viewer).
Materials needed:
Materials needed to configure your offline experiment:
or
or
A USB to mini USB cable (which comes with the USB-200)
Procedure:
1. Connect the photo gate sensor directly to the left side of a charged
BAT-200 module.
2. When ready to collect data press the “Start/Stop” button on the
photo gate sensor, a red light will turn on for the duration of the
experiment.
3. To change the experiment settings first connect to your chosen
device (PC, Mac, tablet, smart device) and select the “Module
setup” button. (For more information on how to change the
experiment settings view quick start procedure section for your
chosen device in this document.)
4. After the experiment has concluded (when the “Start/Stop” button
is pressed again or the data collection period ends) connect the
sensor to your chosen device. (full instructions in each device’s
quick start procedure section)
5. Open NeuLog software.
6. Click the “Off-line experiment” button.
7. Click the “Load data from sensors” button.
8. Select which experimental data to upload. (5 experimental runs can
be stored at one time on the NUL-209 photo gate sensor)
