30AC – 230/1
If this unit has special feature(s) installed, see appendix for part number(s).
Part Number Description 115/1 230/1 Qty.
Refrigeration
R101 Compressor – 120/1 ½ hp 9 1
R100 Compressor – 220/1 ½ hp 9 1
R100-R Relay for Compressor 9 1
R100-SC Start Capacitor for Compressor 9 1
R100-RC Run Capacitor for Compressor 9 1
R120 Condenser – Air Cooled 9 9 1
R120-W Condenser – Water Cooled 9 9 1
R130 Receiver ½ Ton 9 9 1
R140-.5 Expansion Valve 9 9 1
R141-.5 Expansion Valve – ½ hw 9 9 1
R146-.5 Refrigeration Sight Glass 9 9 1
R150 Refrigeration Drier – ¼” 9 9 1
R160 Evaporator (All Copper) 9 9 1
R178 Suction Line Heat Exchanger 9 9 1
R182 High Pressure Switch 9 9 1
R183 Low Pressure Switch 9 9 1
Electrical 9 9
E103 Contactors – 30 Amps 9 9 2
E104 4 Point Terminal Block 9 9 1
E110 - 2 Transformer – 220/1 9 1
E110 -.5 Transformer – 120/1 9 1
E115 Grounding Screw 9 9 1
E122 Switch 9 9 2
E124-3 Pilot Light/Bulb – 24V 9 9 2
E126 Pilot Light/ Housing Assembly 9 9 2
E132 Thermostat 9 9 1
E134 Dial Thermometer 9 9 1
E140 Fan Motor – ¼ hp 9 9 1
E146-16 Fan Blade – 14” 16 Pitch 9 9 1
E146 - H ½ Hub for 14” Fan Blade 9 9 1
E153-16 Fan Guard for 14” Blade 9 9 1
Plumbing
P131 60 PSI Brass Pump 9 9 1
P131-M 1/3 HP 1PH Emerson Motor 9 9 1
P131-C Clamp for Motor 9 9 1
P30 Stainless Steel Tank 9 9 1
9 9 1
