PLANNING DATA
Chiller Installation
The chiller and condenser should be installed on a level surface or sub base. Vibration
isolation is not provided by Schreiber Engineering and should be installed per
requirements of local codes. The bolt pattern diagram contains the corner weights for
chiller and condenser mounted together (AC configuration). (SEE DRAWING ON THE
BACK FOR DETAIL ON CLEARANCE AND WEIGHT INFORMATION)
The chiller should be installed in an area free from dirt and debris than can clog the
condenser coil. It should also not be installed near any places where hot exhaust air
would enter the condenser.
CHILLER (DRY WEIGHT)
2250 lbs
CONDENSER 750 lbs
HVAC Requirements:
If the condenser is installed indoors, adequate fresh air must be brought into the space
and exhausted. If the chiller section only is installed indoors, a small amount of heat is
added to the space and should be accounted for in HVAC load calculations.
HEAT REJECTION (BTU/HR) AIRFLOW (CFM)
CHILLER 2,500 N/A
CONDENSER 243,000 12,000
Electrical Data
MODEL FLA MIN SUPPLY MAX FUSE
15MED-AC-480/3 40.15 48.8 60
15MED-AC-230/3 78.2 95 110
Each chiller has one non-fused disconnect. The branch circuit for the chiller should be
protected by fuses no larger than listed in the above table. If more than one chiller is to
be installed, each chiller requires a dedicated, fused circuit.
REMOTE TERMINAL
The remote terminal can be installed in any indoor location. It is connected to the
chiller via a 6- conductor data cable. It is terminated with phone jack style connectors.
The remote terminal is wall mounted.
