MoTeC SDC3 13 Appendices
SDC3 Installation
The factory centre diff controller box is located on the passenger side behind the glove box.
A standard SDC3 installation involves the replacement of the factory controller circuit board, and the addition of a
cable to connect the CAN bus. To remove the controller, locate the box under the dash, unplug the loom
connector and remove the single bolt holding the bracket.
To remove the factory circuit board, open the case lid (four screws) and undo the circuit board (4 screws).
If a permanent CAN cable is required, a cable entry hole should be made in the case before the SDC3 board is
installed, and the CAN cable should be cable tied to the SDC3 board using the two holes provided next to the
connector.
The SDC3 board is fastened using the 4 screws from the factory board.
