Backplane wiring – Chenbro RM31616 6Gb/s 16-port 3.5 mini-SAS Backplane(80H10331604A0) - Manual User Manual
Page 11
11
16-Port Mini-SAS 6Gb/s Backplane 80H10331604A0 ver. A0
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
w
w
w
.
c
h
e
n
b
r
o
.
c
o
m
Backplane Wiring
Mini-SAS Cable
Discrete HDD failure / activity signal cable
Fan cable
Slim ODD power cable
Slim FDD power cable
Fan Signal cable
Standard 4pin power cable
to slim FDD
adaptor board
to slim ODD
adaptor board
to LED board
from Fan1
from Fan2
fromFan3
from Fan4
to PSU
to HDD Host
to RAID
card HDD
Failure
signal
connector
