7
Parts List Model P350
Item Part Number Description Qty
1 N/A Base 1
2 H18-4-1902-208 Low Press Valve Assy 1
3 601-7-0008-009 Steel Ball 3
4 512-2-0063-104 Compression Spring 2
5 601-7-0012-000 Steel Ball 2
6 552-2-0080-106 Compression Spring 2
7 * Special Washer 2
8 H18-6-1215-100 Nut 2
9 H18-4-1603-107 Release Valve 1
10 * O-ring 1
11 H39-6-1308-100 Iron Plate 1
12 649-1-0050-028 Screw 1
13 H39-6-1502-207 Support Plate 1
14 H39-6-1501-104 End Cap 1
15 671-2-0100-205 Nut 1
16 * O-ring 1
17 H18-6-2112-105 Handle Grip 1
18 505-9-0092-207 Oil Fill Plug (Black) 1
18a H18-4-4000-102 Vent Plug (Brass
&Black
1
19 H39-3-2100-204 Handle 1
20 H39-6-4401-105 Screw Bar 1
21 H39-6-1803-201 Tube 1
22 H18-4-1901-105 High Press Valve Assy 1
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
Item Part Number Description Qty
23 532-8-0040-012 Filter 1
24 * Washer 2
25 H39-6-1603-102 Base Plate 1
26 H39-4-1606-207 Piston Assy 1
26-1 H39-5-1606-102 Large Piston 1
26-2 H39-5-1307-102 Small Piston 1
26-3 666-5-0150-204 C-clip 1
26-4 * Back-up Ring 1
26-5 * O-ring 1
27 644-1-0060-05311 Screw 1
28 H39-6-2108-208 Fixing Pillar 1
29 H39-6-2109-109 Fixing Ring 1
30 * Back-up Ring 1
31 * O-ring 1
32 H39-6-1602-100 Pin 1
33 H39-6-2111-106 Pin 1
34 H39-5-2111-100 Pin 1
35 677-5-0030-109 E-clip 2
36 677-5-0060-108 E-clip 1
37 H39-5-8104-103 Nut 1
38 651-1-0050-103 Screw 5
(*) H39-3-9901-102 Repair Kit 1
