BVA Hydraulics P350, P601S, P1000, P1000AD, P2001 - Manual (Page 11)

11
Parts List Model P1000
Item Part Number Description Qty
1 N/A Base 1
2 H18-5-1602-101 Base Plate 1
3 532-8-0050-024 Filter 1
4 H18-4-1901-105 High Press Valve Assy 1
5 H18-4-1902-208 Low Press Valve Assy 1
6 601-7-0008-009 Steel Ball 3
7 H18-4-1603-107 Release Valve 1
8 * O-ring 1
9 H18-6-1308-107 Iron Plate 1
10 649-1-0050-028 Screw 1
11 512-2-0063-104 Compression Spring 2
12 601-7-0012-000 Steel Ball 2
13 552-2-0080-106 Compression Spring 2
14 * Special Washer 2
15 H18-6-1215-100 Nut 2
16 H18-5-1502-208 Support Plate 1
17 671-2-0100-205 Nut 1
18 * O-ring 1
19 H18-5-1501-105 End Cap 1
20 H18-6-2112-105 Handle Grip 1
21 * Washer 2
22 505-9-0092-207 Oil Fill Plug (Black) 1
22a H18-4-4000-102 Vent Plug
(Brass&Black)
1
23 H18-6-1803-107 Tube 1
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
Item Part Number Description Qty
24 H18-3-2100-100 Handle 1
25 H18-5-4401-207 Screw Bar 1
26 H18-6-1322-101 Washer Base 1
27 649-1-0050-037 Screw 1
28 * O-ring 1
29 * Back-up Ring 1
30 * Back-up Ring 1
31 * O-ring 1
32 H28-4-4406-108 Piston Assy 1
33 H18-6-2114-200 Fixing Pillar 1
34 H18-6-1317-108 Pin 1
35 H18-5-1318-104 Pin 1
36 677-5-0040-102 E-clip 2
37 667-5-0100-005 C-clip 1
38 H18-6-1318-100 Pin 1
39 D05-6-1001-106 Nut 1
40 651-1-0050-103 Screw 5
41 H18-6-1321-200 Hook 1
42 512-2-0060-016 Compression Spring 1
43 661-2-0040-012 Nut 1
44 667-5-0120-001 C-clip 1
45 644-1-0060-071 Screw 1
(*) H18-3-9902-101 Repair Kit 1
