SPECIFICATIONS
Cylinder
Capacity
(tons)
Stroke
(in)
Model
Cylinder
Effective
Area
(in²)
Internal
Pressure at
Capacity
(psi)
Oil
Capacity
(in³)
Weight
(Lbs)
Collapsed
Height
A
(in)
Extended
Height
B
(in)
Cylinder
Bore
C
(in)
Outside
Diameter
D
(in)
Plunger
Diameter
E
(in)
2
3.07
H0203*
0.76
5,263
2.28
2
5.39
8.46
1
1.31
0.87
5
0.63
H0500**
1.1
9,091
0.69
1.85
1.63
2.26
1.18
L2.37xW1.59xH1.63
0.98
1
H0501
1
10,000
1
3.1
4.58
5.58
1.13
1.5
1
3.07
H0503
1
10,000
3.07
3.17
6.65
9.72
1.13
1.5
1
5.08
H0505
1
10,000
5.08
3.93
8.7
13.78
1.13
1.5
1
7.09
H0507
1
10,000
7.09
4.7
10.71
17.8
1.13
1.5
1
9
H0509
1
10,000
9.03
5.5
12.75
21.75
1.12
1.5
1
10
0.98
H1001
2.24
8,928
2.19
3.92
3.62
4.6
1.69
2.26
1.49
2.01
H1002
2.24
8,928
4.5
4.96
4.84
6.85
1.69
2.26
1.49
4.02
H1004
2.24
8,928
9
7.67
6.85
10.87
1.69
2.26
1.49
5.94
H1006
2.24
8,928
13.3
9.45
9.84
15.78
1.69
2.26
1.49
7.95
H1008
2.24
8,928
17.81
11.33
11.85
19.8
1.69
2.26
1.49
9.96
H1010
2.24
8,928
22.31
13.07
13.86
23.82
1.69
2.26
1.49
11.97
H1012
2.24
8,928
26.81
15.04
15.87
27.84
1.69
2.26
1.49
14.02
H1014
2.24
8,928
31.4
16.65
17.72
31.74
1.69
2.26
1.49
15
0.98
H1501
3.14
9,554
3.07
6.9
4.88
5.86
2
2.75
1.63
2.01
H1502
3.14
9,554
6.31
8.53
5.87
7.88
2
2.75
1.63
3.98
H1504
3.14
9,554
12.49
11.13
7.87
11.85
2
2.75
1.63
5.98
H1506
3.14
9,554
18.77
14.83
10.63
16.61
2
2.75
1.63
7.99
H1508
3.14
9,554
25.08
17.33
12.64
20.63
2
2.75
1.63
10
H1510
3.14
9,554
31.4
19.97
14.65
24.65
2
2.75
1.63
12.01
H1512
3.14
9,554
37.71
22.54
16.65
28.66
2
2.75
1.63
14.02
H1514
3.14
9,554
44.02
25.22
18.66
32.68
2
2.75
1.63
25
1.02
H2501
5.15
9,708
5.25
12.06
5.63
6.65
2.56
3.35
2.24
2.01
H2502
5.15
9,708
10.35
14
6.61
8.62
2.56
3.35
2.24
4.02
H2504
5.15
9,708
20.7
18.03
8.62
12.64
2.56
3.35
2.24
6.1
H2506
5.15
9,708
31.41
22.23
10.71
16.81
2.56
3.35
2.24
8.11
H2508
5.15
9,708
41.77
26.27
12.72
20.83
2.56
3.35
2.24
10.12
H2510
5.15
9,708
52.12
30.3
14.72
24.84
2.56
3.35
2.24
12.2
H2512
5.15
9,708
62.83
34.27
16.77
28.97
2.56
3.35
2.24
14.25
H2514
5.15
9,708
73.39
38.3
18.74
32.99
2.56
3.35
2.24
30
8.27
H3008
6.49
9,245
53.67
40.72
15.24
23.51
2.87
4
2.24
