MODELS: H0501, H0503, H0505, H0507 & H0509
Single Acting Cylinders
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Parts List
Item
Part Number for Model:
Description
Qty
H0501
H0503, H0505, H0507 & H0509
1
N/A
Cylinder
1
2
N/A
Ram
1
3
H05-3-4200-105
Saddle Assy
1
3a
H05-6-1103-100
Saddle
1
3b
*
O-ring
1
4
H05-6-2305-107
Protective Cap
1
5
H05-6-1804-100
Upper Bearing
1
6
*
Dust Seal
1
7
*
Bolt
1
8
*
Special Washer
1
9
H05-4-0141-101
H05-4-0143-105 (H0503)
H05-4-0145-109 (H0505)
H05-4-0147-103 (H0507)
H05-4-0149-107 (H0509)
Return Spring Assy
1
10
H05-6-1204-106
Bearing
1
11
*
Back-up Ring
1
12
*
U-cup
1
13
H02-4-6001-104
Female Coupler
1
14
H02-4-6003-108
Dust Cover
1
15
H02-6-1008-105
Rubber Plug
1
16
644-1-0060-200
Bolt
1
(*)
H05-3-9902-102
H05-3-9901-100
Seal Kit
-
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
