Page 7
7
Item
Part No. for Models:
Description
Qty
HPD0906 & HPD0916
HPD1606 & HPD1610
1
N/A
Cylinder
1
2
N/A
Ram
1
3
*
Dust Cap
1
4
F09-5-1804-104
F16-5-1804-101
Upper Bearing
1
5
*
Back-up Ring
1
6
*
U-cup
1
7
*
U-cup
2
8
*
Back-up Ring
1
9
F09-5-1204-100
F16-5-1204-107
Bearing
1
10
*
Back-up Ring
1
11
F09-6-1608-100
F16-6-1608-107
Lower Bearing
1
12
*
Back-up Ring
1
13
*
O-ring
1
14
D05-6-1001-106
Hex. Plug (3/8”-18NPTF)
2
(*)
F09-3-9901-100
F16-3-9901-107
Seal Kit
1
Precision Double
Acting Cylinders
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
MODELS: HPD0906, HPD0910, HPD1606, & HPD1610
Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized
Replacement Parts only.
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
