Step 3
– Select step value
Select the data value you want
programmed for the selected step.
If you enter 0.000, this denotes the
150W DC Electronic Load
8540
Set
V
Recall CC
Short CV
end of the sequence and it will
stop on this step. The maximum
value will depend on the type
selected in previous step. See
programmable range on the right
for reference. In this example, we A B C D
W
30A CR
A OFF Shift
will enter 1.000 A.
Programmable Range: 0.000 (CC) /
0.100 (CV) / 0.100 (CR)
– 30.00 (CC) /
Press C View to go and configure
60.0 (CV) / 4000 (CR)
the next parameter.
Use the
A B
keys to change
cursor position shown by the LED light
next to either A, B, C, or D (These four
denotes cursor position, with A selecting
the most significant figure and D the
least significant figure.
Step 4
– Select delay time
“dt” on the top display refers to
delay time for the selected step. In
this example, we will set it to 5
150W DC Electronic Load
8540
Set
V
Recall CC
Short CV
seconds. A B C D
W
30A CR
Press C View to go and configure
A OFF Shift
the next parameter.
Programmable Range: 0.4 seconds to
25 seconds.
Use the
A B
keys to change
cursor position shown by the LED light
next to either A, B, C, or D (These four
denotes cursor position, with A selecting
the most significant figure and D the
