Specifications:
Number of Video Formats 12:
1: 1920x1080 30i
2: 1920x1080 30p
3: 1920x1080 24p
4: 1280x720 60p
5: 1280x720 30p
6: 1280x720 24p
7: 704x480 60p
8: 704x480 30p
9: 704x480 30i
10: NTSC
11: PAL
12: SECAM
Number of Patterns 14:
1: SMPTE Bars 75%
2: PLUGE
3: Needle
4: Color Bars 75%
5: Cross Hatch [16:9]
6: DVD Aspect Ratio [1.33, 1.78, 1.85, 2.35]
7: Raster
[75% wht, yel, cyn, grn, mag, red, blu, blk]
8: Multiburst
9: Focus
10: Staircase
11: ANSI Gray
12: Window
[2.5 IRE steps from Black to White]
13: Checker
14: Overscan -Bounce
Operation 15 buttons, 1 Power Switch
Y Output 1V peak-to-peak into 75 ohms, on BNC
Pb, Pr Outputs 0.7V peak-to-peak into 75 ohms, on BNC
S-VID Output Luminance Only, on DIN connector
Video Output Buffers Frequency Response 100MHz @ -3dB
Power Supply 9V Battery (Alkaline Battery recommended)
Timing Accuracy < 25ppm (0.0025%)
Video Level error < 1.5%
Size (L x W x D) 3.600" x 6.000" x 1.131" (142 x 79 x 28 mm)
Weight 6.2 oz. (176 g)
Specifications subject to change without notice.
For the most current and up-to-date specifications please visit
www.bkprecision.com
