DDS Function Generators
Models 4007B and 4013B
2
Specifications 4007B 4013B
Frequency Characteristics
Sine 0.1 Hz to 7 MHz 0.1 Hz to 12 MHz
Square 0.1 Hz to 7 MHz 0.1 Hz to 12 MHz
Triangle 0.1 Hz to 1 MHz
Resolution 5 digits or 100 mHz
Accuracy 0.01% ± 0.186 Hz
Output Characteristics
Amplitude Range
20 mVpp to 20 Vpp (open circuit);
10 mVpp to 10 Vpp (into 50 Ω)
Amplitude Resolution 3 digits (1,000 counts)
Amplitude Accuracy ± 2 % ± 20 mV of programmed output from 1.01 V – 10 V
Flatness ± 1 dB to 7 MHz ± 1 dB to 12 MHz
DC Offset Range -4.5 V to 4.5 V (into 50 Ω)*
DC Offset Resolution 10 mV, 3 digits
DC Offset Accuracy ± 2 % ± 10 mV (into 50 Ω)
Output Impedance 50 Ω ± 2%
Output Protection
Protected against short circuit or accidental overvoltage practically available in
electronic laboratories, applied to the main output connector
Waveform Characteristics
Harmonic Distortion
(at 10 Vp-p into 50 Ω)
DC - 100 kHz, -55 dBc
100 kHz - 1 MHz, < -45 dBc
1 MHz – 7 MHz, <-30 dBc
DC - 100 kHz, -55 dBc
100 kHz - 1 MHz, < -45 dBc
1 MHz – 12 MHz, <-30 dBc
Square Rise/Fall Time ≤ 20 ns (10% to 90% at full amplitude into 50 Ω)
Duty Cycle Adjustable 20% - 80% up to 1 MHz for square and triangle
Symmetry Accuracy at 50% ± 1%
Sweep Characteristics
Sweep Shape Linear or Logarithmic, up or down
Sweep Time 20 ms to 100 s
Input and Output
Sync Out TTL pulse at programmed frequency; 50 Ω source impedance
General
Memory Storage 9 instrument settings
Power Requirements 100 V – 240 V AC ± 10%
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature -10 °C to 70 °C (14 °F to 158 °F)
Humidity 95% R.H. 0 °C to 30 °C
Dimensions (W x H x D) 8.39” x 3.46” x 8.27” (213 x 88 x 210 mm)
Weight 4.4 lbs (2 kg)
Electromagnetic Compatibility Meets EMC Directive 2004/108/EC, EN55011, EN55082
Safety Meets Low Voltage Directive 2006/95/EC, EN61010
Three Year Warranty
Supplied Accessories Manual on CD, power cord, certificate of calibration
*Depending on the amplitude setting
Note: All specifications apply to the unit after a temperature stabilization time of 15 minutes over an ambient temperature range of 23 ºC ± 5 ºC.
Specifications are subject to change without notice.
v121112
