DDS Function Generators
Models 4014B and 4040B
2
Output
On/Off button
Main output
USB interface Modulation input connector
Trigger/counter input connector
Rotary
control knob
Color LCD display Numeric keypad
Dedicated
waveform keys
Lin/Log sweep key Modulation
key
Utility
key
Sync output
Easily change all waveform parameters using the
intuitive menu-driven front panel keypad, rotary
control knob, and large color LCD display that
shows a preview of the output waveform.
Convenient waveform and range selection buttons
let users make quick and precise adjustments to
the output signal.
Front panel
Rear panel
Menu function keys
Intuitive user interface
Versatile tools
Easy PC connectivity
The function generators can be programmed
remotely via the USB (virtual COM) interface
using SCPI commands. B&K Precision also offers
application software (available for download at
www.bkprecision.com) that provides virtual front
panel emulation, allowing users to remotely
control their instrument without the need for
programming.
Both models provide AM and FM modulation
along with linear/logarithmic sweep and built-in
counter capabilities. Internal and external sources
can be used for triggering and modulating the
signal.
