Audio Monitor Outputs
Monitor (All) Balanced +20dBu nominal full scale output level, ¼” TRS
Monitor 1 Unbalanced RCA, 2VRMS nominal full scale output level
Monitor 2 Unbalanced RCA, 2VRMS nominal full scale output level
Monitor 3 Unbalanced RCA, 2VRMS nominal full scale output level
Monitor 4 Unbalanced RCA, 2VRMS nominal full scale output level
Trim Control Software controllable, >90dB range, 0.5dB steps
Indicator LEDs
Power Green LED indicator for power “on”
One LED per input channel Green indicates audio activity
Red indicates compression threshold is reached
Computer Interface
Operating System Support Windows XP Home SP1, Windows XP Professional SP1
USB Hi-Speed USB (USB 2.0) required for full functionality
Audio Wave Devices 2 or 4 mono recording devices (1 or 2 stereo)
Mixer Control Full function software control running on host computer
General
Power 85-240VAC, 50-60Hz switchable
AC Input Removable IEC plug
Certifications cUL 1409 or equiv., CE/FCC Part 15 Class A
Size 15” x 11” x 1.5” (395 mm x 270 mm x 65 mm)
Weight approx 5 lbs (2.3 kg)
Operating Environment 0-40C, 0-95% RH non-condensing
