American Expedition Vehicles JK snorkel Kit - Manual (Page 2)

PLEASE READ BEFORE YOU START
TO GUARANTEE A QUALITY INSTALLATION, WE RECOMMEND READING THESE INSTRUCTIONS
THOROUGHLY BEFORE BEGINNING ANY WORK. THESE INSTRUCTIONS ASSUME A CERTAIN AMOUNT
OF MECHANICAL ABILITY AND ARE NOT WRITTEN NOR INTENDED FOR SOMEONE NOT FAMILIAR
WITH AUTO REPAIR.
COUNTERFEIT PRODUCT WARNING
PLEASE BE AWARE THAT THE AEV SNORKEL HAS BEEN COUNTERFEITED. COUNTERFEITERS HAVE
BEEN KNOWN TO USE AEV PART NUMBERS AND INSTRUCTION SHEETS. THE PLASTIC USED IS
INFERIOR TO MATERIALS USED BY AEV. AEV DOES NOT OFFER TECHNICAL SUPPORT OR WARRANTY
ON THESE COUNTERFEIT PRODUCTS . WE RECOMMEND ALWAYS PURCHASING AEV PRODUCTS
THROUGH AN AUTHORIZED AEV DEALER. TO FIND ONE IN YOUR AREA, VISIT AEV-CONVERSIONS.COM.
IF YOU SUSPECT THAT YOU MAY HAVE PURCHASED A COUNTERFEIT AEV PART, YOU MAY CONTACT
AEV FOR VERIFICATION AT 248-926-0256 OR [email protected].
ii
This product is covered under the AEV Parts Limited Warranty, a copy of which can be found at aev-conversions.com/warranty.
INCLUDED PARTS QTY REQUIRED TOOLS
AEV Snorkel 1 Pop-rivet tool
AEV Air Ram 1 Air cut off wheel or body saw
AEV Trim Ring 1 Center punch
Snorkel Bracket A 1 Wax pencil
Snorkel Bracket B 1 Touch up paint
Snorkel Bracket C 1 Masking tape
1/8” SS Rivets for Trim Ring 6 1 3/4” (44.45 mm) hole saw
1/4 - 20 Stainless Steel Bolts 6 1/8” and 5/32” drill bits
Stainless Steel Washers 6 Drill motor
5/32” Rivets for 3.6L Airbox 2 Common hand tools
Hood Cut-out Template 1 Silicone
Anti-Rattle Sleeve 1
