Alpha Technologies Cordex 125-4.4kW - Manual (Page 33)

SIZE DWG NO. TYPE
B
SHEET
TITLE
ISSUE
DATE
OF
TOLERANCES
SCALE
APPROVED
CHECKED
DRAWN
DESIGN MATERIAL
FINISH
FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED
THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF
REVISIONS
LTR DESCRIPTION APPD DATE
REV
X.X 0.04"
X.XX 0.02"
X.XXX 0.01"
[X] 1mm
[X.X] 0.5mm
[X.XX] 0.25mm
030-769-08
CUSTOMER CONNECTION
19" SHELF, 4.4kW CORDEX
PER P.O. and
Doc. 070-024-83
1 2
WH
J.U.
2006/05
2006/05
D2
c 2006 ARGUS TECHNOLOGIES O B
G.S. 2006/05
N.T.S.
REV BY
B ADDED MOUNTING BRACKETS S.D.W.
L1
L2
L1
L2
L1
L2
GND 1.
CAN H 2.
NOT CONNECTED 3.
CAN L 4.
NOT CONNECTED 5.
NOT CONNECTED 6.
GND 1.
CAN H 2.
NOT CONNECTED 3.
CAN L 4.
NOT CONNECTED 5.
NOT CONNECTED 6.
CAN IN RJ12 OFFSET
PIN OUT (J7)
CAN OUT RJ12 OFFSET
PIN OUT (J8)
J8
J7
PROTECTIVE EARTH
TERMINAL
2 PLACES
AC WIREWAY (2 PLACES)
1.3 [34] HOLE FOR
CUSTOMER SUPPLIED
1" CONDUIT FITTING
SEE AC INPUT
DETAILS
AC WIREWAY
BLANK PLATE
REAR VIEWS
SWITCH SETTING FOR CAN TERMINATION
CAN
TERMINATED
CAN
UNTERMINATED
AC INPUT DETAILS
SINGLE PHASE INPUTS, 208V - 277VAC
L1
L2
L1
L2
REMOVE COVERS
