6.4 Factory Ranges and Defaults
The following tables lists the rectifier settings/ranges/defaults; changes are made via the CXC:
Setting Range (minimum to maximum) Default
Float (FL) Voltage 90 – 160V 130.5V
Equalize (EQ) Voltage 90 – 160V 132.9V
Battery Test (BT) Voltage 90 – 160V 106.3V
OVP See note below – 160V 137.8V
Current Limit (CL) 9 – 100% 100%
Power Limit (PL) 0 – 100% 100%
Module Start Delay 0 – 250s 1s
System Start Delay 0 – 600s 0s
Low Voltage Alarm (LVA) 90 – 160V 106.3V
High Voltage Alarm (HVA) 90 – 160V 134.1V
EQ Timeout 1 – 2399h 30h
BT Timeout 1 – 250h 8h
Softstart Ramp-rate Normal/Fast Normal
CL/PL Alarm Enable/Disable Enable
Remote Shutdown Enable/Disable Enable
Ramp Test Enable/Disable Enable
Table C–Cordex 125-4.4kW factory ranges and defaults
NOTE: OVP cannot be set below the present system/FL/EQ/BT voltage setting or the safe mode voltage of 118.9V.
