745-680-B2-002, Rev. B 8
Table 1-1, General Electrical and Mechanical Specifications by Model
(Specifications courtesy of manufacturer)
Type
Normal
Voltage
(V)
Rated
Capacity
C20 (Ah)
Rated Power
(15min, 1.67V,
W)
Dimensions Weight
L
(in/mm)
W
(in/mm)
H
(in/mm) (lb/kg)
SMU-HR 12-9 12 9.0 35.0 5.9/151 2.6/65 4.0/101 5.9/2.7
SMU-HR 12-18 12 20.4 75.0 7.1/181 3.0/77 6.6/167 13.2/6.0
SMU-HR 12-35 12 35.0 140 7.7/195 5.1/130 7.1/180 24.3/11.0
SMU-HR 12-55 12 55.0 198 9.0/228 5.5/139 8.9/225 38.6/17.5
SMU-HR 12-75 12 75.0 270 10.3/261 6.8/173 8.8/224 57.3/26.0
SMU-HR 12-90 12 92.0 310 12.0/305 6.6/168 8.4/212 63.7/28.9
SMU-HR 12-100 12 100 397 13.4/341 6.8/173 9.5/241 75.0/34.0
SMU-HR 12-150 12 154 461 19.1/485 6.8/172 9.5/240 99.2/245.0
The SMU-HR series of Valve Regulated Lead Acid (VRLA) batteries is designed to meet the needs
of many industrial and utility applications. The success of the AlphaCell SMU-HR series is due to a
product design purpose-built for the needs of critical backup requirements, and an industry-leading
manufacturing technology which delivers product consistency. Safety, reliability, and long service life
in standby applications are the result.
Alpha offers a full line of racking solutions to accommodate the SMU-HR series of batteries. SMU-HR
batteries provide easy terminal access for installation and maintenance, and can be upright-, side-, or
end-mounted. The SMU-HR series includes eight models to make it easier to install and maintain the
batteries.
1.1 Features
Require no additional water throughout their life cycle, reducing maintenance costs. •
Specifically designed to meet the requirements of modern electronic equipment. •
Compatible with commonly available recharging systems. •
Compact construction and excellent performance at high rates of discharge provide big •
savings in volume and weight compared to conventional vented batteries.
SMU-HR batteries offer substantial savings in installation and maintenance costs •
compared to conventional vented batteries. No specifically designed rooms are required
and only minimal maintenance is needed during the life of the battery.
SMU-HR batteries are very easy to maneuver. Smaller, more compact, and lighter than •
traditional batteries, SMU-HR batteries are supplied filled and charged so they can be
immediately installed directly into cabinets or on easily assembled racks (also available
from AlphaCell).
With a minimum 10 year design life, the SMU-HR batteries are highly reliable and fully •
comply with established international standards. The SMU-HR range has been fully
tested with respect to charge and discharge characteristics, cycle life, recombination
efficiency, mechanical strength, vibration life, and flame retardancy.
1.2 Typical Electrical and Mechanical Specifications
1.0 Introduction
