Alpha Technologies AlphaCell SMU-HR - Manual (Page 20)

745-680-B2-002, Rev. B 20
SMU-HR 12-75
End voltage 5Min 10Min 15Min 30Min 1h 3h 5h 10h 20h
1.60V 537 368 284 181 108 49.7 33.3 16.2 7.91
1.67V 512 359 270 178 106 46.3 32.0 16.0 7.88
1.70V 500 350 268 177 105 45.7 31.3 15.8 7.88
1.75V 484 342 265 172 103 45.0 30.8 15.8 7.84
1.80V 470 330 263 162 103 43.3 30.0 15.7 7.56
1.85V 420 300 258 158 102 42.5 28.7 15.0 7.37
SMU-HR 12-90
End voltage 5Min 10Min 15Min 30Min 1h 3h 5h 10h 20h
1.60V 643 412 314 189 118 50.9 29.6 19.6 10.3
1.67V 620 401 310 185 117 49.3 29.5 19.5 9.94
1.70V 588 397 307 173 115 47.1 29.1 19.4 9.81
1.75V 584 396 305 168 113 46.0 28.9 19.1 9.57
1.80V 538 390 283 160 107 44.7 28.0 18.9 9.32
1.85V 488 370 256 150 100 43.3 27.1 18.6 8.95
SMU-HR 12-100
End voltage 5Min 10Min 15Min 30Min 1h 3h 5h 10h 20h
1.60V 740 518 405 254 154 58.0 43.3 23.7 10.5
1.67V 714 505 397 253 153 57.7 43.2 23.3 10.5
1.70V 700 496 390 253 152 57.7 43.2 23.2 10.5
1.75V 662 475 378 245 152 57.5 43.0 23.2 10.5
1.80V 594 462 369 240 150 57.2 42.7 23.0 10.2
1.85V 560 441 358 230 146 56.3 41.5 22.7 9.90
SMU-HR 12-150
End voltage 5Min 10Min 15Min 30Min 1h 3h 5h 10h 20h
1.60V 866 597 465 297 195 78.6 54.8 31.8 15.8
1.67V 821 590 461 291 189 78.6 54.8 31.3 15.8
1.70V 767 575 453 284 184 78.6 54.8 31.1 15.8
1.75V 714 537 426 276 182 77.4 54.2 30.6 15.7
1.80V 641 500 401 269 179 76.4 53.3 30.0 15.1
1.85V 513 414 350 246 177 76.1 52.5 29.5 14.2
5.2 Discharge Data with Constant Power, continued
