Alpha Technologies UPE-8 - Manual (Page 9)

745-179-C0-001 Rev. A
9
2. Installation
2.3 Side / Rear Cover Installation Procedure
1. Set BATTERY BREAKER on the power supply to OFF. Set the AC
SERVICE BREAKER to the OFF position.
2. Move batteries as far away as possible from the area where drilling
is taking place. If unsure, remove battery pack from enclosure.
3. Drill eight 9/64” holes at the center punches on the side and back
of the enclosure, directly above and below the louvers.
4. Remove the protective paper from the adhesive strips on
item 1 (4 pcs), and place on either side of both storm covers,
item 8 and 9.
5. Using the rivets provided with the kit, attach the storm covers
to the side and back of the enclosure.
6. Remove any shavings from the interior of the enclosure.
CAUTION
Use extreme caution when drilling into
the battery compartment. Do not allow
drill to penetrate battery!
1
9
8
1
Fig. 4 Side and Rear Cover Placement
