9 033-090-C0-001, Rev. A
1.0 Introduction, continued
1.2 Enclosure Specifications
PWE-SG Component Description
Enclosure
PWE-SG: 30.25” (76.83cm) W x 16.25” (41.27cm) H x 17.0” (43.18cm) D, Weight: 31.0 lbs (14.1 Kg)
(Alpha P/N 033-090-20)
Material Powder-coated aluminum
Hardware Stainless steel (excluding optional GemLocks)
Color Gray (Custom colors available)
Tamper Switch
Optional
NC, with Printed Circuit Board (PCB) jumper (Alpha P/N 745-851-20) •
NO, with PCB jumper (Alpha P/N 745-851-21) •
Safety Ground Bronze stud (Alpha P/N 744-422-20). Optional stainless steel ground available
Lid Removable lift off
Doors
Hinged lift-off removable with stainless steel spring latch. Available with optional door-open prop rod
(Alpha P/N 745-857-20); Gemlock options
Sliding Battery Drawer
Aluminum. Two available options with lock in and lock out slides
Standard option (Alpha P/N 745-088-24) Select if battery weight is less than 300 lbs. •
Heavy duty option (Alpha P/N 745-088-23) Select if battery weight is more than 300 lbs and •
less than 420 lbs.
Enclosure Mounting
Galvanized steel brackets for wall, wood and concrete pole mount.
2 Pole mount brackets (PMB) concrete (Alpha P/N 591-557-20) •
Single 2-point PMB (Alpha P/N 605-352-N2) •
8 inch extension 2-point PMB (Alpha P/N 605-360-N2) •
2 PMB wooden (Alpha P/N 744-670-20) •
2 Wall mount brackets (Alpha P/N 744-800-20) •
Gem Lock Kit Provides additional security for enclosure (Alpha P/N 744-229-20)
Conduit Collocation Kit 6" to 24" separation, 48" uncut length of conduit (Alpha P/N 745-853-20)
Enclosure Environmental
Ratings
NEMA 3R
Battery Configurations
165/185/210 AlphaCell (3 or 4 with or without sliding drawer) •
195/255 AlphaCell FT (3, 4 or 6 without sliding drawer) •
Tel12-125 (3 or 4 with or without sliding drawer) •
Other configurations can be supported •
All AlphaGuard battery configurations •
Battery Retaining Bar Secures batteries within the enclosure. (Alpha P/N 745-154-20)
Battery Cable Kits
Optional
7' extension with all Battery Cable Kits (BCK) (Alpha P/N 875-584-20) •
Heavy Duty (HD), Fused (F), 1 x 36/1 x 48 AlphaCell FT (195/225) 3 or 4 batteries installed •
(Alpha P/N 745-759-20)
HD/F 2 x 36 AlphaCell FT (195/22) (Alpha P/N 745-759-21) •
HD 1 x 36 AlphaCell (165/180/210) (Alpha P/N 874-202-20) •
HD/F 1 x 36 AlphaCell (165/180/210) (Alpha P/N 874-202-21) •
HD/F 1 x 48 AlphaCell (165/180/210) (Alpha P/N 874-845-20) •
HD 1 x 48 AlphaCell (165/180/210) (Alpha P/N 874-845-21) •
Battery Heater Mats
Optional
120VAC with slide tray (Alpha P/N 189-031-10) •
240VAC with slide tray (Alpha P/N 189-031-11) •
120VAC no slide tray (Alpha P/N 189-072-10) •
240VAC no slide tray (Alpha P/N 189-072-11) •
8' line cord extension for 120VAC battery heater mat (BHM) (Alpha P/N 745-854-20) •
8' line cord extension for 240VAC BHM (Alpha P/N 745-854-21) •
Regulatory
CSA C22.2 No. 107.1-01, CSA C22.2 No. 0-M91, CSA C22.2 No. 0.4-04,
CSA C22.2 No. 94-M91, UL 50, UL 1778
Table 1-2, Enclosure Specifications
