Alpha Technologies Underground Battery Vault - Manual (Page 17)

031-040-B0-002 Rev. B
17
2. INSTALLATION
2.3 Battery Connection, continued
+
-
+
-
+
-
12V 24V 36V
+
-
+
-
+
-
12V 24V 36V
+
-
48V
-
48V
+
Fuse on
battery
terminal
To TEMP PROBE connector
To BATTERY INPUT
connector
Black
Brown
Orange Yellow
Black
Brown
Orange
Yellow
Remote temperature sensor
Red
Red
+ -
Fuse on
battery
terminal
AG-CMT-4SC-P-C
AG-CMT-4SC-P-C
2.3.4 Dual 48V Battery String Wiring Diagram
Fig. 2-7 AG-CMT-4SC Wiring for Dual 48V Battery String
To
Status
Monitoring
Card
Locate this connection above high
water mark or source of high humidity
Locate this connection above high water
mark or source of high humidity
Battery Monitoring
cable
To
Second
AlphaGuard
