Page 15
15
041-036-B000-001, Rev. A (07/2013)
2.8 AC Application
1. Start the engine and make sure only the output run indicator light (Green) comes on.
2. Confirm that the equipment to be used is switched off before plugging into the control panel.
Be sure that all equipment are in good working order before connecting them to the generator. If the equipment
begins to operate abnormally, becomes sluggish, or stops suddenly, turn off the generator engine switch
immediately. Disconnect the equipment and examine it for signs of malfunction.
CAUTION!
2.0 Operation
Circuit Breaker
120V AC 20A
NEUTRAL FLOATING
NEUTRE FLOTTANT
DC 12V 8.3A
SYSTEM FLOATING
SYSTÈME FLOTTANT
OFF
ON
OVERLOAD
RUN
LOW OIL
120 V 20A Duplex Receptacle
Run LED (Green)
Figure 2-6, Control Panel AC Applications Components
