25 745-680-C0-002, Rev. B1
6.0 Battery Parameters by Model Number
Parameter
Model Number
220 GOLD-HP 220GxL 195 GOLD-HP 195GxL
Terminal Type Threaded Insert Threaded Insert Threaded Insert Threaded Insert
Bolt Size 1/4"-20 UNC Bolt 1/4"-20 UNC Bolt 1/4"-20 UNC Bolt 1/4"-20 UNC Bolt
Annual Retorque Inch-Lb / N•m 110In-lb / 12.4N•m 110In-lb / 12.4N•m 110In-lb / 12.4N•m 110In-lb / 12.4N•m
Open Circuit Voltage 12.84 12.84 12.84 12.84
Average Float Voltage Range (volts/unit) 13.5 to 13.8 13.5 to 13.8 13.5 to 13.8 13.5 to 13.8
20-Hour Ampere Rate to 1.75 V/C 5.45 5.45 5.00 5.00
Typical Impedance @ 60Hz ohms 0.0050 0.0050 0.0050 0.0050
Typical Conductance 7Hz mohms 960 to 1400 960 to 1400 880 to 1320 880 to 1320
Typical 10 Sec. Voltage @ 100 amp 11.4 11.4 11.3 11.3
Parameter
Model Number
195GxL FT 165GxL 135AGM-P 85GxL-HP
Terminal Type 16mm Insert Threaded Insert Threaded Insert Threaded Insert
Bolt Size M6 thread 1/4"-20 UNC Bolt 1/4"-20 UNC Bolt 10-32 UNC Bolt
Annual Retorque Inch-Pounds / N•m 110In-lb / 12.4N•m 110In-lb / 12.4N•m 110In-lb / 12.4N•m 25In-lb / 2.8N•m
Open Circuit Voltage 12.84 12.84 12.84 12.84
Average Float Voltage Range (volts/unit) 13.5 to 13.8 13.5 to 13.8 13.5 to 13.8 13.5 to 13.8
20-Hour Ampere Rate to 1.75 V/C 5.50 4.30 3.75 2.50
Typical Impedance @ 60Hz ohms 0.0050 0.0055 0.0055 0.0040
Typical Conductance 7Hz mohms 800 to 1200 800 to 1200 900 to 1350 480 to 720
Typical 10 Sec. Voltage @ 100 amp 10.8 11.2 11.2 11.6
Table 3, Battery Parameters, Current Models (threaded insert terminals)
