c 2007 ALPHA TECHNOLOGIES
OUT
IN
JUMPER SETTINGS FOR
CAN TERMINATION
P10
CAN OUT RJ12 OFFSET
PIN OUT (J1)
GND 1.
CAN H 2.
NOT CONNECTED 3.
CAN L 4.
NOT CONNECTED 5.
NOT CONNECTED 6.
CAN IN RJ12 OFFSET
PIN OUT (J2)
GND 1.
CAN H 2.
NOT CONNECTED 3.
CAN L 4.
NOT CONNECTED 5.
NOT CONNECTED 6.
TB16 TB1
IN 1
TB4
IN 4 IN 3 IN 2
TB2 TB3 TB5
IN 5
K1
TB6
IN 6
TB7
IN 7
K2 K5
NC NC
TB8
IN 8
K3
TB9
K1 NO
K4
NO
TB10
K2 NC NO
TB11
K3 NC
TB14
K6
TB13 TB12
K4 NO NC K5 NO NC
K6
TB15
K7 NO NC
K7
NO NC K8
K8
DS1
2 1
CAN
NO
DS2
PWR
J2
P10
J1
TB17
SIZE DWG NO. TYPE
B
SHEET
TITLE
ISSUE
DATE
OF
SCALE
FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED
THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF
REVISIONS
LTR DESCRIPTION APPD DATE
REV 020-702-08
CUSTOMER CONNECTION
300A FRONT ACCESS UDC
4 4
D2 B DIMENSIONS ARE IN INCHES WITH METRIC (mm) IN BRACKETS: INCHES [mm]
NTS
REV BY
LIST 80 - 8 RELAY / 8 DIGITAL 8DIO PCB
DIGITAL INPUTS RELAY OUTPUTS
IN OUT
CAN
+
_
POWER
