SPECIFICATIONS FOR ARGUS TECHNOLOGIES’ FUSE PANEL MODEL 32-0-10A
A RGU S

TECHNOLOGIES 020-103-B1 Rev B
Output
Voltage: 24VDC (List Option 1 or 5)
48VDC (List Option 2 or 6)
Current Capacity: 30 Amps DC maximum per block of 16 fuses
60 Amps DC maximum if common feed used
Interrupting Capacity: 450 Amps maximum at 60VDC resistive
Individual Fuse Rating: Type GMT fuse (0A to 15A) at 60VDC
Input
Voltage: 24VDC (List 1)
48VDC (List 2)
24VDC and 48VDC (List 5,6)
Current: 60 Amps DC maximum (List 1 or 2)
30 Amps DC maximum each for 24VDC and 48VDC (List 5 or 6)
M iscellaneous
Alarms: Alarm indicator for any fuse in a group of 16, ABS
Weight: 0.9 kg (2 lb.)
Size: 44mm H x 432mm W x 158mm D (1.75” H x 17.0” W x 6.2” D)
[all dimensions do not include mounting brackets]
Mounting: Standard equipment rack; 19” or 23”; flush or center
Recommended Connection Wire Sizes (as per UL / CSA)
Ambient Temp=30 deg C: Input: #10 AWG
Output: User dependant
Recommended Application
To be intended for use in any DC power supply system that has outputs of 24VDC and/or 48VDC and
where the application requires from 1 to 32 alarm-equipped fused outputs ranging from 0A to 15A using
GMT-type miniature fuses. The total current drawn through this fuse panel shall not exceed the stated
specifications. The use of both 24VDC and 48VDC inputs/outputs concurrently is supported.
The above information is valid at the time of publication. Consult factory for up-to-date ordering information.
Specifications are subject to change without notice.
