LEDs
The three LEDs, located on the CXCM4 front panel, display the alarm status of the power system, CXCM4 prog-
ress and status during startup, and file transfers.
Alarm Conditions
The CXCM4 illuminates the LED that corresponds to the system alarm status. Each LED color corre-
sponds to a specific alarm status (only one LED is illuminated at a time during alarm conditions.)
Green
OK, no alarms present.
Yellow
Minor alarm is present, no major alarms.
Red
Major alarm is present.
Progress and Status Indications
Base unit validation
All three LEDs are illuminated at the same time.
File transfer
The red LED is illuminated when recovering from an invalid firmware application.
Reset Button
A reset button is located on the front panel to restart the CXCM4 microprocessor. The display reappears approxi-
mately 15 seconds after pressing the reset button. Refer to the software manual for more information.
NOTE:
Always select the shutdown menu item on the LCD before pressing the reset button.
Ethernet Port
The RJ-45 jack and a standard network cable can be used to connect the CXCM4 to a user supplied network
(TCP/IP secured by user) .
Local access (e.g. with a laptop computer) is also possible from the Ethernet port using a standard network
crossover cable.
RS-232 Serial (Craft) Port
Local access to the CXCM4 is possible through the front panel RS-232 serial port with a null modem cable. The
communication protocol also supports a web interface (Microsoft Internet Explorer 7 or greater). The remote
screen display is an enhanced version of the CXC front panel display.
