Alpha Technologies Cordex Controller Panel Mount_Rack Mount - Manual (Page 38)

C
TOP VIEW-EXPANSION BOARD(707-179-20)
LIST 96-EXPANSION BOARD, OUTPUT RELAY, 8 X 1A FORM C, INTERNAL
DETAIL C
SCALE 2 : 1
138 139 140
TB6 TB7 TB8 TB9
NC C1 N0
RELAY
#9
RELAY
#10
NC C2 N0
142 143 141 144 145 146
NC C3 N0
RELAY
#11
RELAY
#12
NC C4 N0
149 148 147 150 151 152
NC C5 N0
RELAY
#13
RELAY
#14
NC C6 N0
155 154 153 156 157 158
NC C7 N0
RELAY
#15
RELAY
#16
NC C8 N0
161 160 159
1
1
REAR VIEW
DETAIL WITH EXPANSION BOARD MOUNTED ON
SUGGESTED WIRE ROUTING
DETAIL
RIBBON CABLE NOT SHOWN
SIZE DWG NO. TYPE
B
SHEET
TITLE
ISSUE
DATE
OF
TOLERANCES
SCALE
APPROVED
CHECKED
DRAWN
DESIGN MATERIAL
FINISH
F O R M A N U F A C T U R I N G W I T H O U T I T S W R I T T E N C O N S E N T .
A R G U S T E C H N O L O G I E S A N D S H A L L N O T B E C O P I E D O R U S E D
T H E S E D E S I G N S A N D S P E C I F I C A T I O N S A R E T H E P R O P E R T Y O F
REVISIONS
LTR DESCRIPTION APPD DATE
REV
X.X 0.04"
X.XX 0.02"
X.XXX 0.01"
[X] 1mm
[X.X] 0.5mm
[X.XX] 0.25mm
747-195-08
CUSTOMER CONNECTION
CXCR/CXCP
....
....
PER P.O. and
Doc. 070-024-83
4 4
EF/RD/JK
EOF
2003/06
2003/06
D2
c 2004 ARGUS TECHNOLOGIES O
C
RD 2003/06
WES 2003/06
1:2
REV BY
